Description
## Applications
Designed for use with liquids, consult Dixon for specific recommendations
## Available Options
Other gasket types are available, contact Dixon.
## Construction
- Nitrile Rubber gasket
- Durable stainless steel cam arm pins
## Features
- Precision machined to rigid tolerances
- Stainless pins will not rust or bind, providing great strength and safety
- Recess holds gasket firmly in place - ensures proper placement
## How It Works
- To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down.
- Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
## Note
Parts are manufactured in Canada, replacement handle: Part # CARP12BZ
## Safety Notes
- Under no circumstances should cam and groove couplings be used for compressed air or steam service!
- Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon.
## Specifications
Produced to interchange with all product produced to Commercial Item Description A-A-59326D
## Prop 65 Warning
**WARNING**: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
Specifications
| Maximum Operating Pressure | 250 PSI |
|---|---|
| Weight | 0.76 lb |
| Break Quantity | 1 |
| Optional Package/Box Quantity | 1 |
| Size | 1-1/4" |
| Material | 356T6 Aluminum |
| Seal | Nitrile Rubber |
| Applications | Designed for use with liquids, consult Dixon for specific recommendations |
| Available Options | Other gasket types are available, contact Dixon. |
| Construction | Nitrile Rubber gasket Durable stainless steel cam arm pins |
| Features | Precision machined to rigid tolerances Stainless pins will not rust or bind, providing great strength and safety Recess holds gasket firmly in place - ensures proper placement |
| How It Works | To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down. Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter. |
| Note | Parts are manufactured in Canada, replacement handle: Part # CARP12BZ |
| Safety Notes | Under no circumstances should cam and groove couplings be used for compressed air or steam service! Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon. |
| Specifications | Produced to interchange with all product produced to Commercial Item Description A-A-59326D |
| Prop 65 Warning | WARNING : This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. |
