Description
## Applications
Designed specifically for blow-out preventer systems on drilling rigs
## Compatibility & Interchange Data
- Stucchi VEP/VEP-HD Series
- DNP FSI-BOP Series
## Construction
- Machined components are manufactured using solid steel bar stock
- Stainless steel retaining rings and springs maximize corrosion resistance and extend service life.
- Steel components are plated using ROHS Compliant Zinc Nickel
- Red powder coated components and external O-rings for easy BOP service identification
- Blow-out Preventer (BOP) coupling critical seals are severe service FKM
- PTFE Anti-Extrusion ring protects main coupling valve seal from dynamic impulse pressure damage
## Note
Rated Flow ∆P=21.75 PSI
## Specifications
- BOP couplings have been fire tested and Lloyd's certified to 700°C (1300°F) in accordance with API 16D. Certificate available upon request.
- Maximum Impulse Pressure : 7000 PSI (48 MPa)
- Burst Pressure Connected: 20000 PSI (138 MPa)
- Burst Pressure Coupler: 14500 PSI (100 MPa)
- Maximum Pressure Connect & Disconnect : 3625 PSI (25 MPa)
- Lloyd's Test Pressure: 5,000 PSI
## Prop 65 Warning
**WARNING**: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
Specifications
| Weight | 3.9 lb |
|---|---|
| Break Quantity | 1 |
| Optional Package/Box Quantity | 1 |
| Material | Steel |
| Maximum OD | 2.70" (68.6 mm) |
| Thread | Female NPTF |
| Seal | FKM |
| Body Size | 1-1/4" |
| Working Pressure | 5,000 PSI (35 MPa) |
| Thread Size | 1-1/4" to 11-1/2" |
| Length | 4.40" (111.8 mm) |
| Hex | 55 mm |
| Flow | 46.4 GPM (174 L/min) |
| Pressure Rating | 5,000 PSI at 70°F (21°C) |
| Applications | Designed specifically for blow-out preventer systems on drilling rigs |
| Compatibility & Interchange Data | Stucchi VEP/VEP-HD Series DNP FSI-BOP Series |
| Construction | Machined components are manufactured using solid steel bar stock Stainless steel retaining rings and springs maximize corrosion resistance and extend service life. Steel components are plated using ROHS Compliant Zinc Nickel Red powder coated components and external O-rings for easy BOP service identification Blow-out Preventer (BOP) coupling critical seals are severe service FKM PTFE Anti-Extrusion ring protects main coupling valve seal from dynamic impulse pressure damage |
| Note | Rated Flow ∆P=21.75 PSI |
| Specifications | BOP couplings have been fire tested and Lloyd's certified to 700°C (1300°F) in accordance with API 16D. Certificate available upon request. Maximum Impulse Pressure : 7000 PSI (48 MPa) Burst Pressure Connected: 20000 PSI (138 MPa) Burst Pressure Coupler: 14500 PSI (100 MPa) Maximum Pressure Connect & Disconnect : 3625 PSI (25 MPa) Lloyd's Test Pressure: 5,000 PSI |
| Prop 65 Warning | WARNING : This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. |
| Maximum Impulse Pressure | 7000 PSI (48 MPa) |
| Burst Pressure Connected | 20000 PSI (138 MPa) |
| Burst Pressure Coupler | 14500 PSI (100 MPa) |
| Maximum Pressure Connect & Disconnect | 3625 PSI (25 MPa) |
| Lloyd's Test Pressure | 5,000 PSI |
