Description
## Available Options
- Contact Dixon for all available option adders
- Standard seal options include: FKM, EPDM, Steam-EP, FDA FKM, Mil-Nitrile, Fuel Nitrile, PTFE and Silicone
- Kalrez® seal options include: 4079, 6375 and 7075
- Valve options include: Unvalved, actuator, steel, brass, 303 stainless steel and 316 stainless steel
## Compatibility & Interchange Data
- Meets dimensional requirements of ISO 7241 Series B
- Interchangeable with Parker-Hannifin 60 Series, Snap-Tite 72-Series, Hansen HK-Series, Faster Series 'HNV', Aeroquip/Eaton FD45, Stucchi Series IRB/IRBO/IRBX
## Construction
- Machined components are manufactured using solid bar stock
- Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life.
- Steel componentry is plated using ROHS Compliant Trivalent Chrome.
- Steel coupler sleeves are hardened to resist deformation and maximize service life.
- Nitrile (Nitrile Rubber) seals are standard
- Redundant O-ring sealing system with Hytrel back-up ring
## Features
- Poppet style shut-off valves
- Designed to prevent fluid loss when disconnected
## Prop 65 Warning
**WARNING**: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
Specifications
| Maximum Operating Pressure | 1000 PSI (70 bar) |
|---|---|
| Weight | 3.9 lb |
| Break Quantity | 1 |
| Optional Package/Box Quantity | 1 |
| Material | Brass |
| Maximum OD | 2.60" (66.0 mm) |
| Thread | Female NPTF |
| Body Size | 1-1/4" |
| Temperature Range | -40°F to 250°F (-40°C to 121°C) |
| Burst Pressure | 6500 PSI (450 bar) |
| Thread Size | 1-1/4" - 11-1/2 |
| Length | 4.43" (112.5 mm) |
| Hex | 2-3/8" |
| Available Options | Contact Dixon for all available option adders Standard seal options include: FKM, EPDM, Steam-EP, FDA FKM, Mil-Nitrile, Fuel Nitrile, PTFE and Silicone Kalrez® seal options include: 4079, 6375 and 7075 Valve options include: Unvalved, actuator, steel, brass, 303 stainless steel and 316 stainless steel |
| Compatibility & Interchange Data | Meets dimensional requirements of ISO 7241 Series B Interchangeable with Parker-Hannifin 60 Series, Snap-Tite 72-Series, Hansen HK-Series, Faster Series 'HNV', Aeroquip/Eaton FD45, Stucchi Series IRB/IRBO/IRBX |
| Construction | Machined components are manufactured using solid bar stock Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life. Steel componentry is plated using ROHS Compliant Trivalent Chrome. Steel coupler sleeves are hardened to resist deformation and maximize service life. Nitrile (Nitrile Rubber) seals are standard Redundant O-ring sealing system with Hytrel back-up ring |
| Features | Poppet style shut-off valves Designed to prevent fluid loss when disconnected |
| Prop 65 Warning | WARNING : This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. |
| Standard seal options include | FKM, EPDM, Steam-EP, FDA FKM, Mil-Nitrile, Fuel Nitrile, PTFE and Silicone |
| Kalrez® seal options include | 4079, 6375 and 7075 |
| Valve options include | Unvalved, actuator, steel, brass, 303 stainless steel and 316 stainless steel |
