Description
## Compatibility & Interchange Data
- European Screw-Together Interchange
- Inteva STG-Series, Faster CVV-Series, DNP PVV3, Voswinkel Type-HS, Stucchi VD Series
## Construction
- Machined components are manufactured using solid bar stock
- Steel retaining rings and springs maximize service life in rugged environments.
- Steel componentry is plated using ROHS Compliant Trivalent Chrome.
- Nitrile (Nitrile Rubber) seals are standard
## Note
Threaded sleeves enable easy connection and disconnection while system is under residual pressure only.
## Prop 65 Warning
**WARNING**: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
Specifications
| Maximum Operating Pressure Metric | 300 Bar |
|---|---|
| Maximum Operating Pressure | 4400 PSI |
| Weight | 4.8 lb |
| Break Quantity | 1 |
| Optional Package/Box Quantity | 1 |
| Material | Steel |
| Maximum OD | 3.14" (79.8 mm) |
| Thread | Female BSPP |
| Body Size | 1-1/4" |
| Temperature Range | -40°F to 250°F (-40°C to 121°C) |
| Burst Pressure | 17600 PSI (1200 bar) |
| Thread Size | 1-1/4"-11 |
| Length | 5.59" (142.0 mm) |
| Compatibility & Interchange Data | European Screw-Together Interchange Inteva STG-Series, Faster CVV-Series, DNP PVV3, Voswinkel Type-HS, Stucchi VD Series |
| Construction | Machined components are manufactured using solid bar stock Steel retaining rings and springs maximize service life in rugged environments. Steel componentry is plated using ROHS Compliant Trivalent Chrome. Nitrile (Nitrile Rubber) seals are standard |
| Note | Threaded sleeves enable easy connection and disconnection while system is under residual pressure only. |
| Prop 65 Warning | WARNING : This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. |
