Pneumatic Fittings

U-Series Universal Pneumatic Female Threaded Coupler

Scraped SKU: u-series-universal-pneumatic-female-threaded-coupler 2026-06-05 09:34:23

Variations (6)

2UF2-B

Length2.32" ( 59.0 mm )
Maximum OD0.92" ( 23.4 mm )
Body Size1/4"
ThreadNPT
Thread Size1/4"-18
SealNitrile
MaterialBrass

2UF3-B

Length2.32" ( 59.0 mm )
Maximum OD0.92" ( 23.4 mm )
Body Size1/4"
ThreadNPT
Thread Size3/8"-18
SealNitrile
MaterialBrass

2UBF2-B

Length2.32" ( 59.0 mm )
Maximum OD0.92" ( 23.4 mm )
Body Size1/4"
ThreadBSPP
Thread Size1/4"-19
SealNitrile
MaterialBrass

2UBF3-B

Length2.32" ( 59.0 mm )
Maximum OD0.92" ( 23.4 mm )
Body Size1/4"
ThreadBSPP
Thread Size3/8"-19
SealNitrile
MaterialBrass

3UF3-B

Length2.54" ( 64.5 mm )
Maximum OD1.09" ( 27.7 mm )
Body Size3/8"
ThreadNPT
Thread Size3/8"-18
SealNitrile
MaterialBrass

3UBF3-B

Length2.54" ( 64.5 mm )
Maximum OD1.09" ( 27.7 mm )
Body Size3/8"
ThreadBSPP
Thread Size3/8"-19
SealNitrile
MaterialBrass
