Counterweight Loading Arm Base Assembly

Scraped SKU: counterweight-loading-arm-base-assembly 2026-06-05 09:15:50

Variations (14)

CW2-LA4-078-0

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	78" reach

CW2-LA4-090-0

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	90" reach

CW2-LA4-102-0

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	102" reach

CW2-LA4-114-0

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	114" reach

CW4-LA4-078-0

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	78" reach

CW4-LA4-090-0

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	90" reach

CW4-LA4-102-0

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	102" reach

CW2-LA4-078-1

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	78" reach

CW2-LA4-090-1

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	90" reach

CW2-LA4-102-1

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	102" reach

CW2-LA4-114-1

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	114" reach

CW4-LA4-078-1

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	78" reach

CW4-LA4-090-1

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	90" reach

CW4-LA4-102-1

Height	40.75"
DN Size	DN100
Flange Size	4"
Nominal Size	4"
Range	102" reach

Specifications

No specifications scraped.

PDF Documents

Loading Arm Ordering Guide Open PDF

Loading Arm Manual Open PDF

Counterweight Loading Arms Open PDF

Loading Arms Open PDF
